Image is a representation for illustration; not a photo of the actual item. Packaging, labeling, and appearance may vary by source.
Pilz 525120 Safety Interlock Switch
Pilz 525120 (PSEN 1.2p-20/8mm/ 1 switch) is a safety interlock switch in the PSEN family designed for monitoring movable guards and machine access points. Manufacturer data lists sensor principle: magnetic, supply voltage: 24 V, and connection type: M8, 4-pin male. It is practical for guard doors, access panels, and safety interlocking systems that depend on the specified sensing method, connection, and protection level.
Specifications
| Product Code | 525120 |
| Alternative Part Number | PSEN 1.2p-20/8mm/ 1 switch |
| Brand | Pilz |
| Product Category | Safety Products Machine Safety Interlock Switches |
| Classification to EN 60947-5-3 | PDDB |
| Coding Level to ISO 14119 | Low |
| Sensor Principle | magnetic |
| Supply Voltage (V) | 24 V |
| Supply Voltage Type U1 | DC |
| Switching Voltage | 24 V |
| Depth Dimension | 36 mm |
| Ambient Temperature | -10 °C |
| Housing Protection Rating | IP65 IP67 |
| Approval | CE UKCA cULus Listed EAC (Eurasian) T√úV |
- Brand: Pilz
Mfr # 525120
$100.41
Special Order
- 12-month warranty
- 30-day returns
- Free shipping: $50+ US · $350+ International
- Sourced & inspected
