Keyence SR-LR1 Code Reader Communication Unit, Handheld DPM
SR-LR1 is an industrial barcode and 2D code reader from Keyence. Keyence lists this part in the catalog as “Communication unit (Ethernet & RS-232C)”. Autofocus and liquid-lens designs hold a read across varying part heights without mechanical adjustment. Read range, code type, and communication interface determine which model fits an application. Applications include work-in-process tracking and shipment verification. Cables, brackets, and lighting accessories are typically separate items.
Specifications
| Product Code | SR-LR1 |
| Brand | Keyence |
| Product Category | Barcode Readers Handheld Scanners |
| Supply Voltage / Current Consumption | 24 VDC ±10% / Approx. 120 mA, or use dedicated AC adapter (12 VDC) / Approx. 230 mA |
| Output Format | Photo MOS relay |
| Leakage Current When OFF | 0.1 mA or less |
| Wireless Communication Distance | Approx. 10 m 32.81' (line-of-sight) |
| Wireless Communication | Bluetooth Ver. 2.1 + EDR Class 2 |
| RS-232C | 9600, 19200, 38400, 57600, 115200 bps No-protocol, MC protocol, SYSWAY, KV STUDIO |
| Ethernet | IEEE 802.3, 10BASE-T / 100BASE-TX TCP/IP, FTP, MC protocol, Omron PLC link, KV STUDIO, EtherNet/IP™, PROFINET |
| Weight | Approx. 160 g |
| Dimensions | 62 × 125.8 × 40 mm 2.44" × 4.95" × 1.57" |
| Ambient Temperature | 0 to +45 °C 32 to 113 °F |
| Number of Points | 3 |
| Maximum Rating | 30 VDC, 100 mA |
- Brand: Keyence
Mfr # SR-LR1
$711.01
Delivery by Mon, Aug 31
Availability: In Stock
- 12-month warranty
- 30-day returns
- Free shipping: $50+ US · $350+ International
- Sourced & inspected
