Image is a representation for illustration; not a photo of the actual item. Packaging, labeling, and appearance may vary by source.
Autonics PET18-5 Inductive Transmission Couplers
The Autonics PET18-5 is an inductive transmission coupler for non-contact signal transfer. Using inductive coupling, it transfers signals across a gap without physical contact, removing the wear associated with mechanical connectors. Because transmission occurs inductively rather than through touching contacts, the coupler tolerates repeated engage and release cycles in moving equipment. Common applications include tool changers, rotating fixtures, and modular automation stations.
Specifications
| Product Code | PET18-5 |
| Brand | Autonics |
| Product Category | Automation and Controls Sensors Transducer Accessories |
| Response Time | Max. 1ms |
| Sensing Side Diameter | M18 |
| Transmission Distance | 5mm |
| Set Transmission Distance | 1 to 4.5mm |
| Approximate Weight | ≈ 121g (≈ 133g) |
| Ambient Temperature Range | -25 to 70℃, storage: -30 to 80℃ |
| Ambient Humidity Range | 35 to 95% RH, storage: 35 to 95% RH |
- Brand: Autonics
Mfr # PET18-5
$43.85
Delivery by Mon, Oct 12
Availability: In Stock
- 12-month warranty
- 30-day returns
- Free shipping: $50+ US · $350+ International
- Sourced & inspected
