Pressure Sensors

Choosing Pressure Sensors components

Selecting a pressure sensor requires matching the pressure range, media, process connection, electrical output, and accuracy to the application. Oversized ranges sacrifice resolution; undersized ranges fail under transient spikes. The process fitting and the wetted material are where most field issues originate.

Specs to confirm before ordering:

Measurement type: gauge (relative to atmosphere), absolute, compound (vacuum + positive), differential
Range, with operating max typically 60–80% of rated full-scale to leave headroom for spikes
Process connection: 1/4" NPT, 1/2" NPT, G1/4, G1/2, sanitary tri-clamp, flush diaphragm
Wetted parts: 316 stainless, Hastelloy, ceramic, for media compatibility
Output: 4–20 mA (2-wire is most common), 0–10 V, 0.5–4.5 V ratiometric, IO-Link, switch contact
Supply voltage: 10–30 VDC for transmitters; 24/120/230 VAC for switches
Accuracy class: typically 0.25%, 0.5%, or 1.0% of span
Electrical connection: DIN 43650, M12, 1/2" NPT conduit, flying leads

For hydraulic applications, pulsation and pressure spikes can be 2–3× steady-state — choose range and over-pressure rating accordingly, and consider a snubber. For viscous, slurry, or food-grade media, a flush diaphragm sensor avoids clogged ports. For pneumatic systems, a switch-only device is often cheaper than a full transmitter if only on/off interlock is needed.

Typical applications: hydraulic press cycle monitoring, pneumatic clamp confirmation, vacuum verification on pick-and-place end-effectors, and pump discharge monitoring on water systems. Legacy machine controls often use a specific pressure-switch part number whose contact form (SPDT, DPDT) and setpoint range cannot be substituted casually — for those, exact OEM match from surplus stock is the safer route.

Request a quote for any obsolete or hard-to-find pressure sensor or switch.

Can you source obsolete pressure transmitters?

Yes. Discontinued Wika, IFM, Keller, and similar models are routinely sourced from surplus and new-old-stock channels. Send the full part number for an accurate quote.

What is the difference between gauge and absolute pressure?

Gauge reads relative to local atmospheric pressure (zero at atmosphere). Absolute reads relative to a perfect vacuum (atmospheric ≈ 14.7 psi at sea level). They are not interchangeable.

Are calibration certificates included?

Manufacturer factory calibration is included where the original certificate is available with the unit. NIST-traceable recalibration can be quoted separately for critical applications.

Can I get a flush-diaphragm version for viscous media?

Yes — flush-diaphragm and sanitary clamp variants are listed where stocked, and can be sourced on request for most major brands.

How are these shipped?

From St. Louis. Free US shipping over $50, free international over $350. Sensors are individually packed with the original or equivalent protective fittings.

What if the sensor reads incorrectly out of the box?

Contact us within 30 days. Returns are accepted hassle-free, and the 12-month functional warranty covers replacement or refund.

Autonics ARIO-C-CL Slim Remote I/O

Autonics ARIO-S-DI08P Slim Remote I/O

Autonics ERB-A-26S-06/10 Flexible Shaft Couplings

Autonics KT-302HS-0810 Display Type Pressure Transmitters

Autonics PA10-V High Performance Sensor Controllers

Autonics PSAN-01CH-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-01CPA-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-01CPH-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-01CPV-RC1/8 Digital Display Pressure Sensors

Autonics PSAN-1CPA-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-1CPH-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-1CPV-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-1CPV-RC1/8 Digital Display Pressure Sensors

Autonics PSAN-1CV-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-D1CPV-NPT1/8 Digital Display Pressure Sensors

Autonics PSAN-L01CH-R1/8 Digital Display Pressure Sensors

Can't Find The Part You Need?
