Name: Beckhoff BK3100 PROFIBUS Bus Coupler - Enicstra
Price: 264.33 USD
Availability: InStock

Number of Bus Terminals: 64
Digital peripheral signals: 512 inputs/outputs
Analog peripheral signals: 64 inputs/outputs (only DP mode)
Configuration: via KS2000 or the controller
Data transfer rates: automatic detection up to 12 Mbaud
Bus interface: 1 x D-sub 9-pin socket with shielding
Data transfer medium: shielded copper cable, 2 x 0.25 mm²

Modular I/O Expansion: Supports up to 64 Beckhoff Bus Terminals for scalable system design.
High Signal Capacity: Processes up to 512 digital I/Os and 64 analog I/Os in PROFIBUS DP mode
Flexible Configuration: Parameterisation via KS2000 software or directly through the PROFIBUS controller.
High-Speed Data Transfer: Automatic baud rate detection up to 12 Mbaud for reliable communication

The Beckhoff BK3100 PROFIBUS Bus Coupler is a robust and versatile device designed to connect Beckhoff’s modular I/O system directly to PROFIBUS networks. By acting as the link between field-level signals and higher-level controllers, the BK3100 enables decentralised automation architectures that combine flexibility, scalability, and reliability.

With support for up to 64 Bus Terminals, the BK3100 offers significant expansion possibilities for digital and analog signal acquisition. This modular approach allows engineers to tailor I/O systems to specific project requirements, avoiding unnecessary hardware while still providing the ability to scale as systems evolve. The coupler can handle 512 digital inputs/outputs, making it suitable for applications with extensive binary signal processing, and supports 64 analog channels when operated in PROFIBUS DP mode.

Communication efficiency is a hallmark of the BK3100. It features automatic baud rate detection up to 12 Mbaud, ensuring optimal performance across different PROFIBUS installations without requiring manual configuration. This flexibility simplifies commissioning and ensures compatibility with a wide range of PROFIBUS master devices.

The coupler is equipped with a 9-pin D-sub socket with integrated shielding as its PROFIBUS interface. Combined with the use of shielded copper cables (2 × 0.25 mm²), this ensures reliable data transmission even in electrically noisy industrial environments. The shielded connection provides robustness and stability, minimising the risk of communication errors and supporting long-term system reliability.

Configuration of the BK3100 can be carried out through Beckhoff’s KS2000 configuration software or directly via the PROFIBUS controller. This dual configuration capability provides flexibility for engineers, making setup and parameterisation efficient and user-friendly.

The device also supports diagnostic functions, enabling users to monitor system health and identify faults quickly. These features reduce downtime and simplify maintenance, making the BK3100 a dependable component in demanding automation environments.

Compact and modular, the BK3100 integrates easily into control cabinets, conserving valuable installation space. Its compatibility with Beckhoff’s extensive range of Bus Terminals means it can be deployed in a wide variety of applications, from machine building and process automation to building control and infrastructure systems.

By bridging Beckhoff’s modular I/O with the widely adopted PROFIBUS standard, the BK3100 ensures interoperability across heterogeneous automation environments. It allows users to leverage Beckhoff’s flexible I/O technology while maintaining compatibility with established PROFIBUS-based controllers and networks.

In summary, the Beckhoff BK3100 PROFIBUS Bus Coupler combines high signal capacity, modular I/O scalability, and robust communication features in a compact form factor. With automatic baud rate detection, flexible configuration options, and reliable shielded connectivity, it provides a trusted solution for integrating Beckhoff Bus Terminals into PROFIBUS networks with efficiency and precision.
